Default e-fan owners: whats a good target coolant temp?

whats a good target temp when having an e-fan? i also have a gryphon programmer which shows me coolant temp. My coolant range right now is between about 190 to 205 when i'm on the highway, depending if i'm going uphill or downhill. i guess average is about 200 degrees maybe.

Should i make my efan power on sooner so that my max temp will be closer to 190-200 maybe? I have several temp settings on my DC Controls temp controller i can choose.. i think i set it at 194 which apparently is the thermostat range.
Reply With Quote
  #2
Old Fri, February 19th, 2010, 03:59 PM
Jackpine's Avatar
Jackpine Jackpine is offline
PHP Groupie

Join Date: Nov 2008
Location: Among Elk, Deer and Javalinas on the Mogollon Rim in Aridzona
Posts: 3,243
Jackpine is a name known to allJackpine is a name known to allJackpine is a name known to allJackpine is a name known to allJackpine is a name known to allJackpine is a name known to all
Default

Quote:
Originally Posted by ballisticmike View Post
whats a good target temp when having an e-fan? i also have a gryphon programmer which shows me coolant temp. My coolant range right now is between about 190 to 205 when i'm on the highway, depending if i'm going uphill or downhill. i guess average is about 200 degrees maybe.

Should i make my efan power on sooner so that my max temp will be closer to 190-200 maybe? I have several temp settings on my DC Controls temp controller i can choose.. i think i set it at 194 which apparently is the thermostat range.
I personally think the coolant temperature should remain in the 200-210 range. The thermostat starts to open at 195, and will be fully open shortly thereafter. The stabilized temperature is controlled by your overall cooling system and the engine load. It SHOULD be above 200 to give you efficient engine operation. With a good pressure seal and 50-50 antifreeze, you won't boil below 250 degrees.

- Jack
__________________

2024 F150 Platinum SCrew 3.5L PowerBoost FX4, Peragon Tonneau Cover, LineX Bed, 35% Window Tint on All Sides and Rear, Full Nose Paint Protection Film, Husky Mud Guards, Lasfit Floor Liners, VIOFO Dash Cam
Reply With Quote
  #3
Old Fri, February 19th, 2010, 06:48 PM
ballisticmike ballisticmike is offline
Whopper

Join Date: Sep 2009
Location: vancouver, canada. also point roberts, WA
Posts: 24
ballisticmike is on a distinguished road
Default

okay thanks. i guess i'll just leave it where its set. Actually i am usually about 200-210 city driving. Last week i did a hyway trip to a ski resort, and only going down long mountain inclines in below freezing temps the temp dipped under 195.
Reply With Quote
  #4
Old Fri, February 19th, 2010, 06:48 PM
408F150 408F150 is offline
Double Whopper

Join Date: Jun 2009
Location: Gilroy, CA
Posts: 33
408F150 is on a distinguished road
Default

I've had good results with the fan set to turn on when the CHT is around 210*, which I think is equal to the fluid being around 196*? You probably want to set it up so comes on right at the temp where the coolant normally sits. My engine runs at exactly 210* all day long unless towing or traffic, which is why I set my fan to come on only at 210* since thats when the engine's self cooling systems need help.
__________________
2007 F150 Screw 5.4L FX4
Reply With Quote
